Characteristics:
|
|
| SEIKO SPT printheads |
|
| 5/7/10/14 printheads ;5 colors (CMYK+W)/7colors(CMYK,LC,LM+W) |
|
| Outstanding printing speed of up to 16.0 sqm/hr* |
|
| Printing format of 1.80m |
|
| Roll to roll and Rigid media capability |
|
| Up to 5.10 centimeter thickness for materials |
|
| Highest printing resolution of 1440 x 1440dpi |
|
| General Information |
| Printing methods: |
Drop-on-demand piezo electric |
| Ink reservoirs: |
Refillable on the fly while printing / 2000ml per color |
| Ink characteristics: |
UV Curable Inks |
| Printhead controls: |
Printhead temperature and voltage are software adjustable |
| Media feeding and take-up system: |
Adjustalbe tensility electromotor for optimal banner tension |
| Media handling options: |
Roll to roll/Rigid Sheets |
| Drying system: |
UV Lamp |
| RIP software: |
Photoprint 5.0 Edition (Windows 2000, Windows Xp, Pro SP2) |
| Color management: |
ICC based color, adjustment curves, density adjustment |
| File formats: |
TIFF，JPEG，Postscript 3，EPS，PDF etc. |
| Electrical requirements: |
50Hz/60Hz，200V-240V,Maximum 30A |
| Environmental requirements: |
Ambient temperature：18-30℃，Relative humidity：40-70% |
| Warranty: |
1 year (please consult your local dealer for details) |
| Technical Specification |
| Model: |
UVA1800-5,UVA1800-7,UVA1800-10,UVA1800-14 (Same specification,different No.of Print heads) |
| Printing heads: |
Seiko spt 255 12pl printheads |
| No. of Print heads: |
5/7/10/14 heads |
| Color: |
5 colors (CMYK+W)/7colors(CMYK,LC,LM+W) |
| Resolution options: |
360x360 / 720x720 / 1440x1440dpi |
| Printing speed: |
| Standard Quality: |
Up to 20.0 sqm/hr * (10/14heads) Up to 12.0 sqm/hr * (5/7heads) |
| High Quality: |
Up to 16.3 sqm/hr * (10/14heads) Up to 8.3 sqm/hr * (5/7heads) |
| Ultra Quality: |
Up to 12.8. sqm/hr * (10/14heads) Up to 5.8. sqm/hr * (5/7heads) |
| Maximum media width: |
180cm |
| Maximum media length: |
No. Limit |
| Maximum media thinkness: |
5.10 cm |
| Media Types: |
Rigid sheet include corrugated, foam core, gatorboard, sintra (PVC), Ceramic tiles,glass,plexiglass,
wood, sheet metal, etc.; Roll to roll include paper, vinlys, adhesive back vinyls, fabrics, etc. |
| Outdoor durability: |
5 years (with Zhongye inks) |
| Dimensions: |
2.7m L x 2.55m W x 1.8m H |
| Net Weight： |
1400kg |
| Gross Weight： |
1600kg |
